Slitting Line
This slitting line includes supportable table, coil car, hydraulic uncoiler, sheet guiding equipment, leveling system, shearing equipment, liner equipment, slitting equipment, coil arm, electric controlling system and recoiler equipment.
Features of Sheet Metal Slitting Machine
1. Supportable table support the material steel coil, so the coil car can feed the coil into the hydraulic uncoiler.
2. Coil car is made of v elevator, lifting oilcan, lifting post, main motor, reducer, train transfer equipment and railway, which has the function of lifting and moving.
3. Hydraulic uncoil consists of the frame, railway, hydraulic cylinder, washer and hydraulic oilcan.
4. Sheet guiding equipment: it consists of flexing supporter panel and oilcan.
5. Rectify equipment consists of one stand of rolls, which can adjust the rolls distance to adapt to different thickness.
6. Shearing equipment can cut at the length when you need.
7. Middle Bridge 1#: guiding the sheet when the sheet twists.
8. Fix the width equipment: limited rolls is mainly adjust the width from 500 mm to 1600 mm at high speed.
9. Slitting equipment consists of the fixable base and movable base,
10. The waste side recoiler: recoiler the waste side after slitting.
11. Middle Bridge 2#: reduce the speed
12. Separate equipment consists of separate rolls and its base, assuring every strip go ahead in their orbits.
13. Recoiler Equipment: Main power: 90kW
14. Hydraulic supporter make the recoil shaft to get more capacity.
15. The unload coil car is near the uncoiler car.
16. Hydraulic pneumatic system consists of motor, oil pump, hydraulic value, oil tank, oilcan, hydraulic pipe, cylinder and value, which control the whole line hydraulic move. Main power: 11kW, Oil pump: pv1-23 (the speed is 33L/min) System pressor: 14Mpa, Air original presser 0.7Mpa.(0.9m3/min).
17. Electrical control consists of the standard electric box, main control panel, vice control panel and the switch box. the whole line including the slitting speed, spot slitting and continuous slit is under control.
Technical Parameters of Slitting Line
Material Specification |
Galvanized steel sheet at stress 235Mpa
(33ksi). less than 450Mpa. |
Thickness |
0.3 to 3.0 mm |
Coil width |
500 to 1600mm |
Coil inner diameter |
508 to 610mm |
Coil out diameter |
less than 2000mm |
Max coil weight |
30T |
Product coil inner diameter |
508mm |
Product coil out diameter |
less than 1500mm |
Product coil weight |
10T |
Production speed |
0 to 120m/min |
The slit
width tolerance of sheet metal slitting machine |
+-0.05 at thickness 0.5 to 1.0mm +-0.1mm at thickness 1.1 to 2.0mm +-0.15mm at thickness 2.1 to 3.0mm |
Slitting straighten tolerance |
0.2mm/m |
the slitting burr |
less than 0.05mm |
Min slit width |
30mm |
The slit strip quantity |
20 strips |
The waste edge |
3 to 15mm |
The quantity of waste edge |
2strips |
The Max weight of waste edge |
less than 150kgs/roll |
The main power |
220kW |
The weight of the line |
about 68T |
The dimension of the line |
250000mm×8500mm |
